Form FactorsATX, EATX, Micro ATX, Mini DTX, Mini ITX, SSI CEB, XL ATX
3.5" Bays2
2.5" Bays3
Expansion Slots8
Cooling
Included Fans0
Included Fan Detailsinstalled Fans - Front: Mobius 140 mm x 3 (non-ARGB) - Available for Black Model Only, SickleFlow ARGB 140 mm x 3 - Available for Silver Model Only; installed Fans - Top: N/A; installed Fans - Rear: Mobius 120 mm x 1 (non-ARGB) - Available for Black Model Only, SickleFlow ARGB 120 mm x 1 - Available for Silver Model Only
Max Fans10
Fan Support120 mm | 140 mm | 180 mm | 200 mm
Radiator Support120 mm | 140 mm | 240 mm | 280 mm | 360 mm | 420 mm
Max Radiator420 mm
Front I/O
Front I/OUSB 3.2 Gen 2x2 Type-C | USB 3.2 Gen 1 Type-A
The MasterFrame 600 is an open-air ATX mid-tower chassis designed for enthusiasts prioritizing maximum airflow and component visibility. Its open frame design supports extensive liquid cooling configurations, accommodating radiators up to 420mm. This case is suitable for high-performance builds, including those with large GPUs up to 485mm, but offers limited dust protection compared to enclosed cases.
Best for: Open-air builds
Pros
Excellent thermal performance due to open design
Supports large radiators up to 420mm
Accommodates very long GPUs (485mm)
Showcase build aesthetic with tempered glass
Versatile mounting options for components
Cons
No dust filtration, requires frequent cleaning
Exposed components susceptible to damage
Large footprint for an ATX mid-tower
Verdict
“Ideal for liquid-cooled showcase builds where aesthetics and maximum airflow are priorities.”
ATX, EATX, Micro ATX, Mini DTX, Mini ITX, SSI CEB, XL ATX
3.5" Bays2
2.5" Bays3
Expansion Slots8
Cooling
Included Fans0
Included Fan Detailsinstalled Fans - Front: Mobius 140 mm x 3 (non-ARGB) - Available for Black Model Only, SickleFlow ARGB 140 mm x 3 - Available for Silver Model Only; installed Fans - Top: N/A; installed Fans - Rear: Mobius 120 mm x 1 (non-ARGB) - Available for Black Model Only, SickleFlow ARGB 120 mm x 1 - Available for Silver Model Only
Max Fans10
Fan Support120 mm | 140 mm | 180 mm | 200 mm
Radiator Support120 mm | 140 mm | 240 mm | 280 mm | 360 mm | 420 mm
Max Radiator420 mm
Front I/O
Front I/OUSB 3.2 Gen 2x2 Type-C | USB 3.2 Gen 1 Type-A
